Bore(mm)

6

10

16

20

25

32

40

Motion Pattern

Double acting,Double acting with spring loaded,Single acting(Spring extend)

Fluid

Air

Max.pressure MPa

0.7MPa

Max.pressure MPa

(Double Acting)

0.2

0.2

1

(Single Acting)

0.3

0.4

0.25

Ambient and fluid temperature

-10~+70℃:(Without auto switch:No freezing)+60℃

Max.operating frequency

(Rubber bumper)

Repeatability Precision(mm)

+1.4 (mm)

*Lubrication

Not required

Port Size

M5×0.8

RC(PT1/8)
