Bore(mm)

10

16

20

25

32

40

Fluid

Air

Motion Pattern

Double-Acting

Max.pressure Mpa(kgf/cn2)

0.6(6.1)

Max.pressure Mpa(kgf/cn2)

0.15(1.5)

0.1(1.0)

Ambient and fluid temperature

-10~60℃

Repeatability Precision(mm)

±0.1mm

Effective gripping force (N) at 0.5 Mpa

14

45

74

131

228

396

Port Size

M5×0.8

G1/8"
