Bore(mm)

6

10

16

20

25

32

Working Medium

Air

Motion Pattern

Double action/Single Action Extrusion type/Single Action Drawing-in Type

Ensured Pressure Resistance

1.0Mpa(10.5kgf/cm2)

Max. Working-pressure

0.7Mpa(7.1kgf/cm2)

Ambient and Medium Temperature

5~+60℃

Cushion

Both ends buffer

Margin of Stroke Error(mm)

+1.0

0

Precision of Piston rod with Non-rotating

±0.8°

±0.5°

Port Size

M5×0.8

G1/8"
