Bore(mm)

12

16

20

25

32

40

50

63

80

100

Working Medium

Air

Motion Pattern

Double action/Single Action Extrusion type/Single Action Drawing-in Type

Ensured Pressure Resistance

15.3kgf/cm2(1.5Mpa)

Max.pressure

10.2kgf/cm2(1.0Mpa)

Environment and fluid temp

5~+60℃

Thread Type

Inner Thread(Standard)/Outer Thread(Optional)

Buffering

NO

Margin of Stroke Error(mm)

1

Installation

Through Hole (Standard)，Inner size on the two sides(Optional)

Port size

M5×0.8

G1/8"

G1/4"

G3/8"
