Bore(mm)

12

16

20

25

32

40

50

63

80

100

Working Medium

Air

Motion Pattern

Double-action

Ensured Pressure Resistance

1.5Mpa(15.3kgf/cm2)

Max.Operating pressure

1.0Mpa(10.2kgf/cm2)

Min. Operating pressure

0.12Mpa(1.2kgf/cm2)

Ambient and Medium Temperature

-10~+60℃

Piston Speed

50~500mm/s

50~400mm/s

Buffer

Rubber Cushion

Tolerance of Stroke

+1.5

0 mm

Bearing

(Slide bearing/ball guide bdaring)

Precision of

Slide Bearing

±0.08°

±0.07°

±0.06°

±0.05°

±0.04°

Piston rod Non-rotating

Ball Guide Bearing

±0.10°

±0.09°

±0.08°

±0.06

±0.05°

Port size

M5×0.8

G1/8"

G1/4"

G3/8"
