Bore(mm)

10

20

30

50

70

100

200

Fluid

Air(non-lube)

Max.pressure

With adjustment bole

1Mpa(10.2kgf/cm2)

R:With Shock Absorber

0.6 MPa (6.1kgf/cm2)/Note

Min.pressure

Basic type

0.1 Mpa(1.0kgf/cm2)

High precision type

0.2 Mpa

0.1 Mpa

-

Ambient and fluid temperature

0~60℃(No freezing)

Cushion

With adjustment bole

Rubber bumper

R:With Shock Absorber

Shock absorber

Angle adjustment range

0~190℃

Maximum rotation

190℃

Piston bore

φ15

φ18

φ21

φ25

φ28

φ32

φ40

Port size

End ports

M5×0.8

RC1/8"

Side ports

M5×0.8
