Bore size(mm)

30

50

63

80

100

Action

Double acting type

Fluid

Air( filtered through 40u filter element)

Max. Operating pressure

1Mpa

Min.operating pressure

0.1Mpa

Proof pressure

1.35Mpa(13.5kgf/cm2)

Ambient & fluid temperature

0-60°C(not freezing)

Backlash

within 1(f30 has a stopper installed, there is no backlash produce under pressure

Tolerance in rotating angle

4/0

Lubrication

Not required

Output torque(N.m)

1.9

9.3

17

32

74

Allowed power

rubber cushion

0.01

0.05

0.12

0.16

0.54

air cushion

0.98

1.5

2

2.9

Rotating time range(min/90 degree)

0.2-1

0.2-2

0.2-3

0.2-4

0.2-5

Port size

M5*0.8

1/8

1/8

1/4

3/8
